MGE Remote Power Management Module Single-Source

Share:
MGE Remote Power Management Module Single-Source MGE Remote Power Management Module Single-Source
MGE Remote Power Management Module Single-Source

MGE Remote Power Management Module Single-Source

PMR1S

MGE Remote Power Management Module Single-Source
Discontinued
Call Sales Support
800-800-4272

PMR1S

MGE Remote Power Management Module Single-Source

  • UPS compatible
    Uniquely designed to accept input power from any single phase, 120V power source such as a UPS, solar panel or other alternative energy power inputs.

Cabinet Power Distribution Features & Benefits

  • Pretested breakers
    All breakers are pretested at the factory, enhancing reliability.
  • Multiple distribution options
    Superior design flexibility enables a wide range of customer requirements to be addressed.
  • LCD graphics display
    Text and mimic diagrams that display modes of operation, system parameters and alarms.
  • Efficient cable management
    Organizes the routing of cables, which simplifies maintenance or future expansion.
  • Front-access servicing
    Simplifies installation and UPS maintenance while minimizing space requirements.
Product Distribution
Product Distribution

Antigua & Barbuda , Anguilla , Netherlands Antilles , Argentina , Barbados , Bermuda , Bolivia , Brazil , Bahamas , Belize , Canada , Chile , Colombia , Costa Rica , Dominica , Dominican Republic , Ecuador , Grenada , French Guiana , Guadeloupe , Guatemala , Guyana , Honduras , Haiti , Jamaica , St. Kitts & Nevis , St. Lucia , Madagascar , Martinique , Mauritius , Mexico , Nicaragua , Panama , Peru , Puerto Rico , Paraguay , Réunion , El Salvador , Turks & Caicos Islands , Trinidad & Tobago , United States , Uruguay , St. Vincent & Grenadines , Venezuela , U.S. Virgin Islands , Mayotte

Print Technical Specification

Output

  • Nominal Output Voltage
    120V , 208V 3PH
  • Maximum Total Current Draw
    310
  • Output Connections
    (1) Hard wire 5-wire (3P + N + E) (Battery Backup)

Input

  • Nominal Input Voltage
    120V , 208V 3PH
  • Input frequency
    60 Hz
  • Input Connections
    Hard wire 5-wire (3P + N + E)
  • Maximum Input Current
    310A
  • Maximum Line Current
    310A

Physical

  • Maximum Height
    72.2inches ( 1834MM , 183.4CM )
  • Maximum Width
    57.48inches ( 1460MM , 146.0CM )
  • Maximum Depth
    13.98inches ( 355MM , 35.5CM )
  • Net Weight
    471.0lbs. ( 213.64KG )
  • Shipping weight
    471.0lbs. ( 213.64KG )
  • Shipping Height
    72.2inches ( 1834MM , 183.4CM )
  • Shipping Width
    13.98inches ( 355MM , 35.5CM )
  • Shipping Depth
    57.48inches ( 1460MM , 146.0CM )
  • Color
    Beige

Environmental

  • Operating Temperature
    14 - 104 °F ( -10 - 40 °C )
  • Operating Relative Humidity
    10 - 90 %
  • Operating Elevation
    0 - 3333ft ( 0 - 1015.9meters )
  • Storage Temperature
    -40 - 60 °C
  • Storage Relative Humidity
    10 - 90 %
  • Storage Elevation
    0 - 30000ft ( 0 - 9144meters )

Conformance

  • Approvals
    CSA 22.2 No. 950, UL listed
  • Standard warranty
    1 year repair or replace
Manuals and Warranties
Title
Size
Updated On

Title

Remote Power Management Module Operation Manual
PDF
PDF

Size

681KB

Updated On

2023-10-04

Title

Remote Power Management Module Installation Manual
PDF
PDF

Size

1516KB

Updated On

2023-10-04

Installation Manual
Brochure
Title
Size
Updated On

Title

Single or Multi-Source Remote Power Management Module Brochure
PDF
PDF

Size

270KB

Updated On

2023-10-04

Brochure for MGE RPMM displaying features and specifications
Title
Size
Updated On
MGE Power Management Module, Mechanicals
90-505030-00, INST DWG PMR084
CAD Source File
1741KB
2023-10-04

90-505030-00, INST DWG PMR084
PDF
471KB
2023-10-04

90-505031-00, INST DWG PMR168B
CAD Source File
2097KB
2021-09-14

90-505031-00, INST DWG PMR168B
PDF
497KB
2021-09-14

90-505032-00, INST DWG PMR168S
CAD Source File
2641KB
2023-10-04

90-505032-00, INST DWG PMR168S
PDF
550KB
2023-10-04
