Output

• Nominal Output Voltage
  120V , 200V , 208V
• Efficiency at Full Load
  99 % %
• Other Output Voltages
  240
• Overload Protection
  Yes
• Maximum Total Current Draw
  100
• Output Connections
  (1) Hard wire 4-wire (2P + N + E) (Battery Backup)
  (1) NEMA L14-30R (Battery Backup)
  (3) NEMA L5-20R (Battery Backup)

Input

• Nominal Input Voltage
  208V
• Input frequency
  50/60 Hz
• Input Connections
  Hard wire 3-wire (2P + E), Hard wire 4-wire (2P + N + E)
• Efficiency at Full Load
  99 % %
• Load Power Factor Range
  0 to 1
• Load Capacity
  20000VA
• Maximum Input Current
  100A
• Maximum Line Current
  100A

Physical

• Maximum Height
  7.01inches ( 178MM , 17.8CM )
• Maximum Width
  17.01inches ( 432MM , 43.2CM )
• Maximum Depth
  26.5inches ( 673MM , 67.3CM )
• Rack Height
  4U
• Net Weight
  51.1lbs. ( 23.18KG )
• Shipping weight
  74.16lbs. ( 33.64KG )
• Shipping Height
  12.01inches ( 305MM , 30.5CM )
• Shipping Width
  39.02inches ( 991MM , 99.1CM )
• Shipping Depth
  24.02inches ( 610MM , 61.0CM )
• Color
  Black

Environmental

• Operating Temperature
  -4 - 122 °F ( -20 - 50 °C )
• Operating Relative Humidity
  0 - 95 %
• Operating Elevation
  0 - 15000ft ( 0 - 4572meters )
• Storage Temperature
  -40 - 65 °C
• Storage Relative Humidity
  0 - 95 %
• Storage Elevation
  0 - 50000ft ( 0 - 15240meters )

Conformance

• Approvals
  CSA, GOST
• Standard warranty
  2 years (parts only)
