Specifications
| Lead time | Special Order - Call for Quoted Lead Times |
|---|
| Main Input Voltage | 400 V 3 phases |
|---|---|
| Main Output Voltage | 400 V 3 phases |
| Other Output Voltage | 380 V 400 V 415 V |
| Output connector type | Hard wire 4-wire (3P + E) 1 Hard wire 5 wire (3P + N + E) 1 Hard wire 3-wire (3P) 1 Hard wire 4-wire (3P + N) 1 Hard wire 4-wire (3P + PEN) 1 |
| Provided equipment | Installation guide User manual |
| Colour | Grey |
|---|---|
| Height | 190 cm |
| Width | 71.5 cm |
| Depth | 82.5 cm |
| Net weight | 215 kg |
| Mounting location | Front |
| Mounting preference | No preference |
| Mounting mode | Not rack-mountable |
| Network frequency | 45...65 Hz |
|---|---|
| Number of input connectors | 1 hard wire 4-wire (3P + E) 1 hard wire 4-wire (3P + N) 1 hard wire 4-wire (3P + PEN) 1 hard wire 5 wire (3P + N + E) |
| Max line current | 360 A |
| Input current limits | 60 A |
| Load capacity | 41568 VA |
| Power factor | 0.5 leading and lagging |
| Maximum crest factor | 3.5 |
| Max current draw | 60 A |
|---|---|
| Protection type | Circuit breaker |
| Efficiency | 99.1 % |
| Product certifications | CE TÜV |
|---|---|
| Standards | EN 60950 |
| Ambient air temperature for operation | 0…40 °C |
|---|---|
| Relative humidity | 20…80 % |
| Operating altitude | 0...3333 ft |
| Ambient air temperature for storage | -40…70 °C |
| Storage altitude | 0.00…9144.00 m |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 203 cm |
| Package 1 Width | 80 cm |
| Package 1 Length | 94 cm |
| Package 1 Weight | 235 kg |
| Warranty | 1 year repair or replace |
|---|
Sustainability
Green PremiumTM label is Schneider Electric’s commitment to delivering products with best-in-class environmental performance.
Green Premium promises compliance with the latest regulations, transparency on environmental impacts, as well as circular and low-CO2 products.
Learn moreEU RoHS Directive
Not applicable, out of EU RoHS legal scope
