StruxureWare Data Center Expert Basic Management Pack
AP9482
Take-back
Specifications
| Presentation | StruxureWare Data Center Expert Basic Management Pack provides a complete, surveillance, environmental, and physical infrastructure monitoring solution. Includes: 1 NetBotz Room Monitor 355 (with 120/240V PoE Injector), 1 NetBotz Door Switch Sensor for Rooms or 3rd Party Racks - 50 ft, 1 StruxureWare Data Center Expert Basic appliance with 25-Node License, 1 StruxureWare Data Center Expert Basic Software Support Contract |
|---|---|
| Lead time | Usually Ships within 2 Weeks |
| Number of rack unit | 1U |
|---|---|
| Number of cables | 2 |
| Communication port protocol | DHCP DNS HTTP HTTPS Modbus SMTP SMS SNMP v1 SNMP v3 SSL TCP/IP |
| Provided equipment | 1 node surveillance license key 25-node license key Documentation CD Installation guide |
| Colour | Black |
|---|---|
| Height | 4.4 cm |
| Width | 54.6 cm |
| Depth | 38.1 cm |
| Net weight | 9.55 kg |
| Mounting location | Front |
| Mounting preference | No preference |
| Mounting mode | Not rack-mountable |
| Standards | UL 60950 |
|---|
| Ambient air temperature for operation | 10…35 °C |
|---|---|
| Operating altitude | 0...10000 ft |
| Relative humidity | 5…90 % |
| Ambient air temperature for storage | -35…60 °C |
| Storage altitude | 0.00…9144.00 m |
| Storage Relative Humidity | 5…95 % |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 30.5 cm |
| Package 1 Width | 78.7 cm |
| Package 1 Length | 62.9 cm |
| Package 1 Weight | 19.09 kg |
| Warranty | 2 years repair or replace |
|---|
Sustainability
Green PremiumTM label is Schneider Electric’s commitment to delivering products with best-in-class environmental performance.
Green Premium promises compliance with the latest regulations, transparency on environmental impacts, as well as circular and low-CO2 products.
Learn moreResource performance
Take-back program available
Well-being performance
REACh free of SVHC
REACh Regulation
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
